Highlights MULTI-MASTER Family with New Exchangeable Solid Carbide Ball Nose Heads for Machining Contoured Surfaces in Aluminum Alloys Head Features 3 flutes Higher productivity to reduce process time Nominal diameter range 8-25mm Suitable for machining aluminum and copper alloys, (ISO N group of application) Head designation: MM EBA-…3… The heads are sharp and uncoated Carbide grade IC08 The advantageous combination of different MULTI-MASTER shank geometries and shank materials significantly improves tool dynamic behavior and ensures stable cutting in various milling applications. The new heads are intended for roughing and finishing applications in the aerospace, medical, and automotive industries. These new heads will increase the capabilities of MULTI-MASTER products in the field of profile milling, especially when machining complicated curve-based surfaces.

Highlights Advanced Face Mills with 8-Edge S890 SZMU 1005 Inserts Following the success of the NEODO S890…08 family, ISCAR is expanding the NEODO S890 line by introducing new face mills, the S890 FSZ…R10, which feature a 90-degree cutting edge angle. The new NEODO S890 FSZ …R10 face mills, featuring a 90° cutting edge angle, are equipped with square double-sided S890 SZMU 10… inserts that offer 8 cutting edges. These face mills are available in a broad diameter range of 40-160 mm. The new family is designed for rough to semi-finish operations, aimed at high efficiency face milling applications, primarily targeting steel and cast-iron components. The new family provides customers with a versatile, efficient, and economical solution for milling operations, delivering excellent performance under various cutting conditions, including machining interrupted surfaces. Additionally, the advanced cutting geometry of the NEODO indexable mill significantly reduces cutting forces, ensuring smooth cutting and lower power consumption. The advanced design, which combines a robust insert structure, a durable cutter body, secure mounting, and progressive carbide grades, offers customers an innovative solution for applications requiring face and square shoulder machining, as well as milling close to shoulders when faced with workpiece or work-holding fixture constraints.

Highlights ISCAR Unveils New Pentagonal Shaped POMG Insert for High-Efficiency Applications Features Double-sided Insert with 10 corners High feed machining, up to 1.5 mm/rev Range Medium-Rough with up to 5mm depth of cut Very firm dovetail pocket clamping Insert with wiper configuration

Dove-tailed pocket Secure dovetail pocket clamping the tools were designed with a unique captive pocket with dove-tail clamping system that provide an extremely rigid clamping.

Wiper configuration Each corner of the insert has a wiper geometry that ensures high-quality machined surfaces, even at high feed rates.

A single insert suitable for two applications using 14.5° and 55° approach angles. For high-feed turning applications, use a tool with a 14.5° approach angle
