Product Information
▶ New coating and new tool geometry gives outstanding cutting performance and wear resistance.
▶ Excellent performance when cutting steels, up to HRc55
▶ Due to Multiple Helix on 1/8" and over diameter end mills, vibration is minimized and tool life increased.
▶ For 1/32" and under 1/32" diameter sizes, double neck increases tool rigidity and minimizes vibration.
▶ Excellent for Rib Processing of various depths
| EDP No. | Mill Diameter | Shank Diameter | Length of Cut | Length Below Shank | Overall Length |
|---|---|---|---|---|---|
| D1 | D2 | L1 | L3 | L2 | |
| GMF22955 | 1/8 | 1/4 | 3/16 | 3/4 | 2-3/8 |
| GMF22956 | 1/8 | 1/4 | 3/16 | 1 | 2-3/4 |
| GMF22012 | 3/16 | 1/4 | 1/4 | 3/8 | 2 |
| GMF22957 | 3/16 | 1/4 | 1/4 | 1/2 | 2 |
| GMF22958 | 3/16 | 1/4 | 1/4 | 5/8 | 2-3/8 |
| GMF22959 | 3/16 | 1/4 | 1/4 | 11/16 | 2-3/8 |
| GMF22960 | 3/16 | 1/4 | 1/4 | 3/4 | 2-3/8 |
| GMF22961 | 3/16 | 1/4 | 1/4 | 1 | 2-3/4 |
| GMF22962 | 3/16 | 1/4 | 1/4 | 1-3/16 | 2-3/4 |
| GMF22013 | 13/64 | 1/4 | 5/16 | 3/4 | 2-3/8 |
| GMF22963 | 13/64 | 1/4 | 5/16 | 1-3/16 | 2-3/4 |
| GMF22964 | 13/64 | 1/4 | 5/16 | 1-3/8 | 3 |
| GMF22965 | 13/64 | 1/4 | 5/16 | 1-1/2 | 3-1/8 |
| GMF22966 | 13/64 | 1/4 | 5/16 | 2 | 3-1/2 |
| GMF22016 | 1/4 | 1/4 | 3/8 | 5/8 | 2-3/8 |
| GMF22967 | 1/4 | 1/4 | 3/8 | 3/4 | 2-3/8 |
| GMF22968 | 1/4 | 1/4 | 3/8 | 1-3/16 | 2-3/4 |
| GMF22020 | 5/16 | 5/16 | 1/2 | 1 | 2-3/4 |
| GMF22024 | 3/8 | 3/8 | 5/8 | 1-3/16 | 3 |
| GMF22969 | 3/8 | 3/8 | 5/8 | 1-3/4 | 4 |
| GMF22032 | 1/2 | 1/2 | 3/4 | 1-3/8 | 3-1/8 |
| GMF22970 | 1/2 | 1/2 | 3/4 | 2 | 4-1/4 |
